Emotive Acoustic Technology :
Point-Sound-Source Speaker System
Ultra Wide Range Reproduction
Phase Precision Driver (Coaxial Flat 2-way Speaker Unit)
High-quality Network Circuit
High Rigidity Entasis Form Cabinet
Technics Definitive Design :
White High Gloss Finish
Entasis Form Enclosure
Magnet Fixed Fabric Grille
Type Coaxial 2-way 2 Speaker Bass Reflex
Speaker Unit :
Woofer / Tweeter: Coaxial 16-cm Flat Type x 1 / 1.9-cm Dome type x 1
Crossover Frequency 2.5 kHz
Frequency Range 40 Hz – 100 kHz (-16 dB), 45 Hz – 80 kHz (-10 dB)
Sound pressure level 85 dB / 2.83 V (m)
Impedance 4 Ω
Input Power (IEC) 50 W (Rated), 100 W (Max)
Dimensions (W x H x D) 220 x 336 x 286 mm (including net and terminals)
Weight Approx. 8.5 kg (/pc)
Accessories Speaker Cable (1.2 m) x 2 *1, Operating Instructions
