Specifications
Turntable section
-
Type: Direct Drive Manual Turntable
- Turntable Speeds: 33-1/3, 45 and 78 r/min
- Adjust Range: ±8 %, ±16 %
- Starting Torque: 2.2 kg-cm
- Build-up Characteristics: 0.7 s. from Standstill to 33-1/3 r/min
- Wow And Flutter: 0.025 % W.R.M.S.
- Rumble: 78 dB (IEC 98A weighted)
Turntable Platter
-
Aluminium diecast
- Diameter : 332 mm
- Weight : Approx. 2.5 kg (Including rubber sheet)
Tonearm Section
-
Type: Universal Static Balance
- Effective Length: 230 mm
- Overhang: 15 mm
- Tracking Error Angle: Within 2° 32′ (at the outer groove of 30 cm record), Within 0° 32′ (at the inner groove of 30 cm record)
- Offset Angle: 22°
- Arm-height Adjustment Range: 0 – 6 mm
- Stylus Pressure Adjustment Range: 0 – 4 g (Direct Reading)
- Head Shell Weight: Approx. 7.6 g
Applicable Cartridge Weight Range (including Headshell)
-
(without auxiliary weight)
- 5.6 – 12.0 g
- 14.3 – 20.7 g (including head shell)
- (with auxiliary weight)
- 10.0 – 16.4 g
- 18.7 – 25.1 g (including head shell)
Cartridge Mounting Dimension: JIS 12.7 mm (1/2″) interval
Head Shell Terminal Lug: 1.2 mmφ 4-pin terminal lug
Terminals
-
Audio Output: PHONO (Pin Jack) x 1, EARTH TERMINAL x 1
General
-
Power Supply: AC 110 – 240 V, 50 / 60 Hz
- Power Consumption: 11 W Approx., 0.2 W (Standby)
- Dimensions (W x H x D): 453 x 173 x 372 mm
- Weight: Approx. 11.5 kg
Accessories
-
Turntable, Turntable sheet, Dust cover, EP record adaptor,Balance weight, Auxiliary weight, Head shell, Overhang gauge, Screw set for cartridge, PHONO cable, PHONO earth lead, AC power supply cord, Owner’s Manual
